Detail of the Jumbo Coiler Double

Efficient Dual Nail Coiling Solutions for High-Speed Production.

Previous image DOUBLE-JC Next image

Jumbo Coiler Double from ZEUS TECHNO INC

Jumbo Coiler Double is a versatile machine designed for high-speed nail coiling. With the capacity to handle up to 3,000 nails per coil, it efficiently produces ring shank nails ranging from 1.6 to 3.77 mm in diameter and 19 to 100 mm in length. Its dual coiling capabilities and robust construction make it an ideal choice for nail manufacturing processes demanding both speed and precision.

No videos available for DOUBLE-JC

Specifications:

Model:
DOUBLE-JC
Nail Diameter Range:
1,6 - 3,77 mm / 0.625" - 0.148"
Nail Length Range:
19 - 100 mm / ³/₄" - 4"
Electric Power:
3 kVA, 3P, 210 - 230 V, 50 - 60 Hz
Bobbin Inner Diameter:
32 - 85 mm / 1.26" - 3.346"
Bobbin Outer Diameter:
Up to 380 mm / 14.961"
Nails Per Coil:
Up to 3 000 pcs
Weight Kg-Lbs:
300 kg / 700 lbs
Air Supply:
6 bar / 87 psi / (One 1/2" hose)
Weight:
300 kg
Depth:
1 100 mm
Height:
800 mm
Width:
790 mm
